Controller comes with O2 Bypasses OX-032 and OX-033. Your stock O2 connections need to be disconnected and the bypasses installed.
YELLOW zone has a TIMEOUT after 5 seconds to allow for a large shot of fuel during acceleration. The range of adjustment is from 20% to 50%. The zone is reset each time after either entering the top end RED zone or dropping back into the cruise GREEN zone.
The GREEN zone engages at 1500 rpm with a GREEN/BLUE setting of 8.
Factory injector connections DO look different from the MT Pockets Performance controller connectors, but the male and female connections will plug in ok.
Installation of Injector Harness is front and rear specific - Your bike is equipped with Harley's Engine Idle Temperature Management System (EITMS). When engine temperature exceeds 284? F, the EITMS will turn off the rear cylinder fuel injector. Idle speed will be maintained, however the rear cylinder will become an "air pump" which will work to cool the engine. MT Pockets Performance controllers power-up through our channel 1 injector connection. The connector pair with double pinned RED and YELLOW wires is channel 1 and should be connected to the FRONT cylinder. Click image to the right to view example.
|
